스마트 전력 반도체를 활용하여 자가소비 분산형 에너지를 만듭니다.

반도체

Smart Highside Power Analog Switch Device

Features

Overload protection

Current limitation

Short circuit protection

Overtemperature protection

Diagnostic feedback with load current sense

Read device status with serial interface (SPI)

Indicate device status with LED driver output

Application

Power switch with current sense diagnostic feedback for up to 54V DC grounded loads

Most suitable for loads with high inrush current like lamps and motors; all types of resistive and inductive loads

Replaces electromechanical relays, fuses and discrete circuits

General Description

N channel power MOSFET with charge pump, bridge diode rectified input and diagnostic feedback with load current sense, integrated in high performance BCDMOS technology.
Fully protected by embedded protection.

Device Summary

Device Summary
Operating Voltage VDD 6.0 ...54 V
Load Current IL 60 A
On-state Resistance RON 3.0
Short circuit current limitation ILSC 300 A
Output clamp VON(CL) 60 V
